Product Overview
The Stainless Steel Transfer Ton Drum, produced byWuxi Sifang Youxin Co., Ltd. , is a specialized industrial container designed for the safe transfer, storage, and transportation of high-value or sensitive liquid materials. Built with high-quality SUS 304 or SUS 316L stainless steel, this drum ensures excellent corrosion resistance, purity retention, and mechanical durability during repeated operations in demanding industrial environments.
With a nominal capacity of 1000 liters (1 ton), the transfer drum integrates superior design, seamless welding, and precision engineering to provide a leak-proof, easy-to-clean, and reusable solution for modern production processes. It is particularly suited for applications in the chemical, new energy, food, pharmaceutical, and fine materials industries, where maintaining material integrity and minimizing contamination are crucial.
This model represents a versatile, eco-friendly, and cost-efficient alternative to conventional intermediate bulk containers (IBCs), ensuring operational efficiency and sustainability throughout the entire supply chain.
Product Specifications
Product Name: Stainless Steel Transfer Ton Drum
Nominal Capacity: 1000 liters (customizable 800L – 1200L)
Material: SUS 304 / SUS 316L stainless steel
Wall Thickness: 1.2 mm – 2.0 mm
Inner Surface Treatment: Polished or electropolished (Ra ≤ 0.4 μm optional)
Outer Surface Treatment: Brushed, sandblasted, or passivated finish
Structure Type: Single-layer or double-layer (optional insulation or reinforcement)
Top Design: Closed top with safety vent and filling port
Bottom Design: Conical or flat bottom with discharge valve
Sealing Type: High-grade silicone, PTFE, or EPDM gaskets
Operating Pressure: Atmospheric or slightly pressurized (≤ 0.3 MPa)
Working Temperature: -40°C to +200°C
Testing Standards: ISO 9001, GB/T 325.1, UN/DOT, FDA & GMP compliance
Handling Compatibility: Forklift, pallet, and crane-compatible lifting lugs
Key Product Advantages
1.Superior Corrosion Resistance
Made from SUS 304 or SUS 316L stainless steel, the drum withstands long-term exposure to electrolytes, acids, alkalis, and solvents without degradation.
2.High Purity and Hygiene
The smooth, electropolished internal surface prevents material adhesion and bacterial growth—ideal for high-purity chemical and pharmaceutical use.
3.Robust Mechanical Strength
Thick-walled stainless steel and reinforced design resist impact and vibration during transfer and transportation operations.
4.Safe and Leak-proof
Precision TIG welding with argon protection ensures complete seam penetration and zero leakage, even under pressurized conditions.
5.Reusable and Cost-efficient
Designed for multiple uses, the drum supports sustainable logistics and significantly reduces the cost of single-use packaging.
6.Easy Handling and Operation
Equipped with standardized lifting lugs, forklift access, and ergonomic discharge valves for efficient loading and unloading.
7.Customizable Configurations
Available with heating jackets, insulation layers, sight glasses, or level sensors to meet diverse process needs.
8.Eco-friendly Design
100% recyclable stainless steel and long service life contribute to a circular, low-carbon industrial supply chain.
Product Composition and Structure
Drum Body:
Cylindrical stainless steel construction for strength and durability.
Internal polishing ensures cleanliness and chemical compatibility.
Top Section:
Includes a sealed manhole, vent valve, and filling port.
Optional pressure gauge or nitrogen purge port available.
Bottom Section:
Conical or flat bottom design facilitates complete drainage.
Integrated stainless steel outlet valve for smooth discharge.
Sealing Components:
Chemical-resistant gaskets made from PTFE, EPDM, or silicone ensure leak-free performance.
Support Frame:
Reinforced stainless steel frame compatible with forklift and pallet transport.
Allows safe stacking and secure transport during movement between production zones.
Optional Accessories:
Sight glass, heating system, thermometer, safety valve, and labeling plate.
Assembly and Manufacturing Process
Material Selection: Certified stainless steel sourced from premium mills.
Rolling and Welding: Drum body formed by precision rolling and TIG welded under argon protection.
Surface Treatment: Internal polishing (mechanical or electrochemical); external brushing or passivation.
Component Integration: Installation of valves, ports, and sealing elements.
Testing Procedures:
Hydrostatic pressure test
Air leak test
Vibration and drop simulation test
Final Inspection: Dimensional accuracy, weld integrity, and surface quality checked before shipment.
Applications
The Stainless Steel Transfer Ton Drum is designed for industries where safe liquid transfer, purity preservation, and process continuity are essential:
New Energy Industry: Safe handling and transfer of lithium battery electrolytes and conductive solutions.
Chemical Industry: Transport and storage of acids, solvents, and resin intermediates.
Pharmaceutical and Biotech: Sterile liquid transfer within cleanroom environments.
Food and Beverage: Hygienic transfer of concentrated juices, dairy ingredients, and flavor compounds.
Semiconductor and Electronics: Ultra-clean liquid handling for etching and plating chemicals.
Quality Assurance
Each transfer drum produced by Wuxi Sifang Youxin Co., Ltd. undergoes strict quality verification to ensure long-term reliability and compliance with international standards:
Hydrostatic Pressure Test: Ensures structural and sealing integrity.
Surface Roughness Measurement: Confirms hygienic and chemical-grade finish.
Leak and Vacuum Test: Detects any microscopic imperfections.
Thermal and Vibration Testing: Simulates long-distance transportation conditions.
Documentation and Traceability: Each unit is provided with a serial number and inspection report.
Frequently Asked Questions (FAQ)
Q1: What is the main function of a transfer ton drum?
It is designed for the safe and efficient transfer of liquids between production, storage, and transport systems.
Q2: Can it be used for high-purity electrolytes?
Yes. The polished stainless steel interior ensures chemical compatibility and purity maintenance.
Q3: Can it handle pressurized liquids?
Yes. The drum is tested and certified for light pressurization up to 0.3 MPa.
Q4: Is the drum reusable?
Absolutely. Its stainless steel structure and durable design make it suitable for long-term repeated use.
Q5: Are customization options available?
Yes. Capacity, outlet type, insulation, and additional fittings can be customized according to process needs.
Conclusion
The Stainless Steel Transfer Ton Drum from Wuxi Sifang Youxin Co., Ltd. is a high-quality, reliable, and reusable solution for transferring and storing sensitive or high-value liquids.
Its corrosion-resistant construction, seamless welding, and high-purity surface finish make it ideal for industries demanding precision, safety, and cleanliness.
Whether transferring electrolytes, fine chemicals, or food-grade materials, this drum provides outstanding performance, operational efficiency, and long service life, embodying the durability and craftsmanship that define Sifang’s stainless steel packaging technology.
